Equipment

Most of our machines were bought as brand new, made by renowned manufactures. Our machinery contians milling machines (3 & 5 axes), die-sinkers, wire-cut machines and one machine for drilling starting holes. Providing high-precision components developed by A.D. Tech would not be feasible without quality control processes. In each process, strict quality checks are performed. Extensive quality control processes enable to ensure expected quality level of provided services. We set our mold standards higher every day, we invest in advanced quality control and measurement equipment. It allows us to correctly set and control all parameters on each step of production. We are able to properly set details, control geometry, dimensions, generate and adjust programs during treatment process. We implement system of identification chips for each detail and tool. Palletizing and grip of electrodes are supported by Erowa work holding system. Properly prepared information is sent to our machines by LAN connection. We also have possibility to remote control a few of our machines. Our machinery:

Mazak QTN 250-IIMY - CNC lathe including Y-axis and milling tools

• Made in Japan
• Year of production: 2014r.
• Steering: Mazatrol Nexus 2
• Number of tools: 12
• Number of driven tools: 12
• Maximum machining diameter: 380mm
• Maximum lathing length: 504 mm
• Travel: X230mm,Y100mm,Z575mm
• Rotating maximum speed: 4,000 min-¹

DMC 835 V Vertical machining centre

• Made in Germany
• Year of production: 2008
• Steering: Siemens 840D
• Travel: X835mm,Y510mm,Z510mm
• Positioning accuracy: 0.008mm
• Rotating maximum speed: 10,000 min-¹
• Workspace: 1000x560 mm

DMC 63V Vertical machining centre

• Made in Germany
• Year of production: 1998
• Steering: Sinumerik
• Tool magazine: 24 positions
• Travel: X630mm,Y500mm,Z500mm
• Rotating maximum speed: 10,000 min-¹
• Workspace: 800x500 mm

DMC 63V Vertical machining centre

• Made in Germany
• Year of production: 1999
• Steering: Sinumerik
• Tool magazine: 24 positions
• Travel: X630mm,Y500mm,Z500mm
• Rotating maximum speed: 10,000 min-¹
• Workspace: 800x500 mm

DMC 1035V Vertical machining centre

• Made in Germany
• Purchased as new in 2008
• Steering: Heidenhain TNC 530
• Tool magazine: 20 positions
• Optical axes
• Sensor of tool and detail
• Travel: X1035mm, Y560mm, Z560mm
• Positioning accuracy: 0.008mm
• Rotating maximum speed: 10,000 min-¹

DMV 70 milling machine

• Made in Germany
• Purchased as new in 2012
• Steering: Heidenhain TNC 530
• Tool magazine: 30 positions
• Optical axes
• Sensor of tool and detail
• Travel: X760mm, Y600mm, Z520mm
• Positioning accuracy: 0.006mm
• Rotating maximum speed: 10,000 min-¹

Mikron HPM 600 Vertical machining centre

• Purchased as new in 2008
• Steering: Heidenhain TNC 530 dual-processor
• Tool magazine: 60 positions
• Optical axes
• Sensor of tool(via laser) and detail
• Travel: X600mm, Y500mm, Z600mm
• Positioning accuracy: 0.005mm
• Rotating maximum speed: 42,000 min-¹!!!

Digma 500 HS - CNC milling machine

• Made in Germany
• Purchased in 2012 (year of production 1998)
• Steering: Heidenhain Atek HS Plus
• Tool magazine: 30 positions
• Optical axes
• Sensor of tool(via laser) and detail
• Travel: X500mm, Y400mm, Z500mm
• Positioning accuracy: 0.005mm
• Rotating maximum speed: 40,000 min-¹!!!

CharmillesRoboform 35P - two machines

• Made in Switzerland
• Purchased in 2010 i 2011 (year of production 2001 and 2003)
• Steering: Charmilles CNC
• Electrodes magazine: 54 positions (including QCRi)
• Pallets magazine: 4 positions
• Optical axes
• Travel: X350mm, Y250mm, Z320mm
• Positioning accuracy: 0.005mm
• C Axis Rotation 360º

CharmillesRoboform 200

• Made in Switzerland
• Purchased in 2007 (year of production 1991)
• Steering: Charmilles CNC
• Optical axes
• Travel: X350mm, Y250mm, Z320mm
• Positioning accuracy: 0.008mm
• C Axis Rotation 360º

AgieCharmilles Drill 11 - hole drilling machine

• Electrode diameter 0.35mm up to 3mm
• Made in China
• Year of production 2008
• Steering: CNC
• Travel: X350mm, Y270mm, Z250mm
• Positioning accuracy: 0.02mm

AgieCharmilles CUT30 - wire-cutting machine

• Made in Switzerland/China
• Year of production 2008
• Steering: CUT30 CNC
• Available wire diameters 0.15 up to 0.33
• Optical axes
• Travel: X600mm, Y400mm, Z370mm
• Max. detail height: 370mm
• Positioning accuracy: 0.004mm
• Surface roughness: Ra 0.33
• Ability to cut up to the angle 30° for 100mm
• Automatic threading and rethreading
• Automatic thermal stabilization with active cooling and dielectric de-ionization

2x Sodick AG400L Premium - wire-cutting machine

• Made in Japan
• Year of production 2012
• Steering: LP2WH
• Available wire diameters 0.05 up to 0.33
• Optical axes
• Travel: X400mm, Y300mm, Z250mm (Max. detail height: 250mm)
• Positioning accuracy: 0.001mm
• Positioning accuracy of W axis 0.0005°
• Surface roughness: Ra 0.1
• Linear Motor Drives X, Y, U, V
• Ability to cut up to the angle 25° for 80mm
• Automatic threading and rethreading
• Automatic thermal stabilization with active cooling and dielectric de-ionization
• Ceramic components

Sodick AG40L - die-sinker

• Made in Japan
• Year of production 2013
• Steering: LP20
• Optical axes
• Linear Motor Drives X, Y i Z
• Travel: X400mm, Y300mm, Z270mm
• Higher positioning accuracy of C-Axis
